UTi730E Enhanced Thermal Camera

UTi730E is an advanced thermal camera with Wi-Fi capability. Its large 3.5” IPS display screen can clearly display 320×240 thermal resolution 2MP visual camera, or a blended image of both. UTi730E’s 5200mAh detachable battery pack is also convenient for easy and quick battery change, allowing continuously work for long periods of time.

REQUEST A QUOTE DOWNLOAD CATLOGUE

Features

3.5”IPS display screen (640×480 Pixels)
IR resolution: 320×240
Temperature measurement range: -20℃to 550℃ / -4℉ to 1022℉
Auto alarm for high/low temperature
Auto tracking for hot spot/cold spot
On screen analyzer :5 Points/1 Line/3 Rectangles/3 Circles
Image capture
Digital camera resolution: 2MP
Digital zoom: 2x, 4x
Image modes: Thermal, Visual image, Fusion, PIP
Color palettes: 7(White hot, Black hot, Red hot, Ironbow, HC Rainbow, Rainbow, Lava)
Isotherm(Auto/Ratio/Below/Above/Section/Manual)
LED flashlight
Wi-Fi connection through Mobile App
QR Code – photo management
PC software: analysis and real-time image projection
5200mAh replaceable battery pack (Type-C rechargeable)
1/4”tripod mounting hole
IP54
2m drop proof

Specifications

Technical Data
Display	3.5″ IPS (640×480)
IR resolution(Pixels)	320×240
Spectral range	8~14µm
Pixel size	12µm
Frame rate	≤9Hz
Thermal sensitivity(NETD)	≤65mK
Focus	Focus Free
Field of view(FOV)	56°(H) × 42°(V)
Temperature measurement range	-20℃~550℃
Accuracy	±2℃ or ±2% whichever is greater

Functions

Color palettes	White Hot, Black Hot, Red Hot, Ironbow, Rainbow HC, Rainbow, Lava
Image modes	Thermal, Visual image, Fusion, PIP
On-screen analyzer	5 Points/1 Line/3 Rectangles/3 Circles
Isotherm	Auto/Ratio/Below/Above/Section/Manual
Hi/Lo temperature alarm	LCD animation & LED flashlight
Hi/Lo temperature tracking	✔
Digital camera resolution	2MP
Digital zoom	2x, 4x
Wi-Fi	✔
LED lighting	✔
Analysis software	PC+APP

General Characteristics

Battery	5200mAh detachable Li-ion battery pack (UT-M17)
Operating time	≥3 hours (with Wi-Fi off)
USB	Type-C
Image storage format	JPG
Protection	IP54 & 2m drop proof
Certificates	CE, UKCA, FCC, RoHS
Languages	EN, FR, DE, ES, RU
Weight	654g
Dimension	260mm×97mm×99mm

Packing Details

Standard accessories	Type-C USB cable, Li-ion battery pack, English Manual, Documents Download Operation Guide
Standard individual packing	Toolbox & Gift box
Standard Qty per carton	1pcs
Standard carton size	400mm×185mm×345mm
Standard carton G.W.	3.7kg

PCBA inspection, motor inspection, automotive maintenance, solar panel inspection, power distribution cabinet inspection, electricity facilities inspection, mechanical equipment inspection, heating equipment inspection, building&HVAC inspection etc.
