Features
| Technical Data | |
| Display | 3.5” TFT Touch (640×480) |
| IR resolution(Pixels) | 256×192 |
| Spectral range | 8~14µm |
| Pixel size | 12µm |
| Frame rate | ≤25Hz |
| Thermal sensitivity(NETD) | ≤50mK |
| Focus | Focus Free |
| Field of view(FOV) | 56°(H) × 42°(V) |
| Spatial resolution(IFOV) | 3.75mrad |
| Temperature measurement range | -20℃~550℃ |
| Accuracy | ±2℃ or ±2% whichever is greater |
| Functions | |
| Color palettes | White Hot, Black Hot, Red Hot, Ironbow, Lava, Rainbow, Rainbow HC |
| Image modes | Thermal, Visual image, Fusion (T-Mix), PIP |
| On screen analyzer | 5 Points/1 Line/ 3 Rectangles/ 3 Circles |
| Isotherm | Auto/Manual/Above/Below/Section/Ratio |
| Hi/Lo temperature alarm | LCD animation & LED flashlight |
| Hi/Lo temperature tracking | √ |
| Digital camera resolution | 2MP |
| Digital zoom | 1.0~8× continuous |
| Video recording | √ |
| Wi-Fi / Wi-Fi live streaming | √ |
| Bluetooth | √ |
| LED lighting | √ |
| Analysis software | PC+APP |
| General Characteristics | |
| Battery | 1800mAh rechargeable Li-ion battery |
| Operating time | ≥2.2 hours (with Wi-Fi off) |
| USB | Type-C |
| Storage | 12GB Internal |
| Image storage format | JPG |
| Video storage format | .avi |
| Protection | IP54 & 1m drop proof |
| Certificates | CE, FCC, RoHS |
| Languages | EN, FR, DE, ES, IT, SV, PL, CZ |
| Weight | 213g |
| Dimension | 133.05mmx85.4mmx24.1mm |
