UT335 Series Handheld Digital Gauss Meter

The UT335 series handheld digital gauss meter is a compact, high-sensitivity, wide-range magnetic field detector for measuring the magnetic field strength on magnet surfaces. It delivers accurate, precise, and stable readings. Featuring an HD TFT display with a wide viewing angle and an intuitive, user-friendly UI, it is easy to operate.

REQUEST A QUOTE

Compare
Categories: , ,
Description

Features of UT335 Series Handheld Digital Gauss Meter

  • 0–3000 mT / 0–30 kGs, Gs/mT Switchable
  • Selectable Accuracy: ±1% / ±2% / ±5%
  • Auto N/S Detection & Zero Calibration
  • Audible & Visual Overrange Alarm
  • 50 Groups Data Storage
  • Full-color TFT Display
  • Rechargeable Li-ion Battery, 16h Working Time

Specifications

UT335A

UT335B

UT335C

Accuracy

±5%

±2%

±1%

Measurement Range

0–30 kGs / 0–3000 mT

Magnetic field resolution

0.01 mT / 0.01 Gs

Sensor type

Hall sensor

Display

Color TFT

Unit Switch

mT / Gs

Polarity Display

✔

Hold Value

✔

Peak Display

✔

Count Test

✔

Quality Inspection Test

✔

Calibration

✔

Backlight

✔

Alarm

Audible & visual alarm

Data Storage

50 groups

Working Temperature

-20~60℃ (Sensor of Test Pen in Maximum 125℃)

Battery Life

About 16 h (Continuous Running Mode)

Charging Interface

Type-C

Specifications

Battery

3.7V 750mAh Li-ion battery

Product size

Gauss Meter 140×63×27mm (excl. probe)

Product net weight

Gauss Meter approx. 120g; probe approx. 32g

Accessories

 Handheld Digital Gauss Meter, Probe, Gift Box, Charging Cord, User Manual
Ultra-thin Clamp:
2-unity
3-unity

UT335 English Manual

UT335 Series DataSheet
