Features of UT206C 1000A AC Clamp Meter
Certificates: CE/cETLus/RoHS
| Model | UT206C | ||
| Current(AC) | 60.00A | 0.01A | ± (2.0%+10) |
| 600.0A | 0.1A | ± (2.0%+5) | |
| 1000A | 1A | ± (2.0%+5) | |
| Frequency(ACA) | 45Hz～400Hz | 0.01Hz～0.1Hz | ± (0.1%+3) |
| Voltage(AC) | 6.000V | 0.001V | ± (1.2%+5) |
| 60.00V | 0.01V | ||
| 600.0V | 0.1V | ||
| VFD(AC) | 600.0V | 0.1V | ± (8%) |
| Frequency(ACV) | 10Hz～100kHz | 0.01Hz～0.1kHz | ± (0.1%+3) |
| Voltage(DC) | 6.000V | 0.001V | ± (1.0%+2) |
| 60.00V | 0.01V | ||
| 600.0V | 0.1V | ||
| Resistance (Ω) | 600.0Ω | 0.1Ω | ±(1.0%+5) |
| 6.000kΩ | 0.001kΩ | ±(1.0%+2) | |
| 60.00kΩ | 0.01kΩ | ||
| 600.0kΩ | 0.1kΩ | ||
| 1.000MΩ | 0.001MΩ | ||
| Capacitance(F) | 6.000μF | 0.001uF | ± (2%+5) |
| 60.00μF | 0.01uF | ± (5%+5) | |
| 600.0μF | 0.1uF | ||
| 6.00mF | 0.01mF | ± (10%) | |
| 10.00mF | 0.01mF | ||
| Features | |||
| Clamp opening size | 33mm | ||
| Display count | 6000 | ||
| True RMS | ✔ | ||
| Clamp thick | 10mm | ||
| Continuity | ✔ | ||
| Auto identification | Resistance/Continuity/Diode | ||
| Data hold | ✔ | ||
| Backlight | ✔ | ||
| Category rating | CAT III 300V CAT II 600V | ||
| Characteristic | |||
| Power supply | 1.5V AAA * 2 | ||
| Product weight | About 130g | ||
| Product dimension | 190 × 68 × 20mm | ||
| Accessories | Batteries, testing probe, manual, cloth bag | ||
