High-Low Temperature (Humid Heat) Test Chamber

The high and low temperature and humidity test chamber is a reliability testing equipment that simulates the combined environment of temperature and humidity. It can simultaneously control low temperature, high temperature, constant humid heat, and alternating humid heat, and is used to test the moisture-proof, insulation, mold prevention and structural stability of products in humid and alternating hot and cold environments.

REQUEST A QUOTE

Compare
Category:
Description
  • External humidifier: Easy to clean, less prone to scaling.
  • Water system: Supports automatic water replenishment, highly water-saving.
  • Water quality filtration: Built-in ion exchange resin filtration, which can effectively prevent the humidifier from getting clogged.
  • Observation window: is made of multi-layer vacuum heated tempered glass, which ensures that there is no frosting or condensation even in low-temperature and high-humidity environments, and the view is clear.

How to Choose a Sensor?

  • Dry-wet bulb method: Easy to maintain, resistant to high temperature and humidity, suitable for most industrial testing scenarios.
  • Capacitive sensor: Quick response, no need to replace the gauze, suitable for low humidity environments and high-precision scientific research testing.
Model TAH-23L TAH-64L TAH-80L TAH-100L TAH-120L TAH-150L TAH-225L TAH-408L TAH-800L TAH-1000L
Control System Balance temperature and humidity control system
Temperature range -20℃～150℃；-40℃～150℃；-70℃～150℃ (Rapid temperature change, linear throughout the entire process, non-linear selectable)
Humidity range 20℃～98%R.H
Temperature fluctuation ±0.5℃
Humidity fluctuation ±2.5%R.H
Temperature deviation ±2.0℃
Humidity deviation ±3%R.H(≥75%R.H）/±5%R.H(<75%R.H）
Heating up time -20℃～150℃ around 45 minutes； -40℃～150℃ around 60 minutes；-70℃～150℃ around75 minutes
Cooling time 20℃～-20℃ around 40minutes； 20℃～-40℃ around 60 minutes；20℃～-70℃ around 85minutes
Inner size（cm） Ｗ 30 40 40 50 50 50 60 68 100 100
Ｈ 30 40 50 50 50 60 75 80 100 100
Ｄ 25 40 40 40 48 50 50 75 80 100
Outer size（cm） Ｗ 50 60 60 70 70 70 80 88 120 120
Ｈ 125 140 155 155 155 161 171 176 195 195
Ｄ 90 110 110 115 123 125 125 150 155 175
Inner material ＳＵＳ３０４ Advanced stainless steel
Outer material Cold rolled steel plate surface treatment by electrostatic spraying or SUS304 high-grade stainless steel
Insulation material High density polyurethane foam and glass fiber
Freezing system Air cooled (optional water-cooled)
Controller LCD color touch screen, Chinese/English display, program, communication function
Protector Non fuse switch, compressor overpressure, overheating, overcurrent protection, overtemperature protection, fan overload protection, fuse, dry burning machine protector, water shortage protection switch, fault warning system, alarm
Standard accessories One observation window for the three-layer vacuum layer, one Ø 5cm test hole, two sets of experimental racks, one illumination board inside the box, four indicator lights, four mobile work wheels, one humidification water tank, a 2-meter power cord, and a communication interface (customizable according to requirements)
Environmental temperature for use 5℃～35℃
Supply power AC380±10% 50HZ Three-phase four wire + PE
3488c0c7f4fbebf2b3d9f3ad8540085c
a84fd8b4f71d96de8b374e2edef0bdae
fb970105f0ed1317487191b7ae320e26
fa365bf7d2d719ad0fe26075d147ac97

Compliance & Standards

  • GB/T 2423.1/2/3/4
  • MIL-STD-202G
  • IEC 60068-2-78

Why use pure water or distilled water?

The impurities present in tap water can easily form scale, causing blockages in the humidification pipeline and reducing the accuracy of the humidity sensor's detection.

How often should the humidity sensor wick be replaced?

Based on the water quality and usage frequency, it is recommended to replace it every 3 months. This device comes with a box of replacement parts as a standard.

Can the equipment undergo a stability test lasting for 30 days or even longer?

OK. The equipment is equipped with automatic water replenishment function in case of water shortage and multiple protection functions against overheating. It can support long-term continuous operation without human intervention.
