The ANFS(F) series 3-phase AC power supply adopts FPGA digital control, instantaneous waveform control, and high-frequency pulse width modulation (SPWM) technologies. It has the advantages of fast response speed, high output accuracy, and superior waveform quality; it can withstand 3 times the rated current impact, a variety of output modes, which can achieve "one machine with multiple functions" to meet the needs of customers for flexible use; it adopts 8-inch color LCD with exquisite and high-grade appearance, and digital keys make the operation more convenient—mainly used in applications such as home appliances, motors, and production lines. It is a solution that meets the basic needs of traditional industries and provides an alternative power supply for equipment upgrades. It also provides laboratories, quality inspection units, scientific research institutes, and other applications with a more flexible power configuration scheme.

Adopt FPGA digital technology, realize accuracy control and high-quality sine wave output;
Advanced power management modes: three-phase standard mode, three-phase unbalance mode (three-phase voltage can be adjusted independently, phase difference 0~359.9° adjustable), three-phase independent mode (three-phase voltage, frequency, all can be adjusted independently), parallel single-phase mode (three parallel single-phase outputs);
Operating in overcurrent shock (up to 3 times the rated current)within 2s, start the impact load of 1/3 capacity of the power supply directly;
Adjustable voltage and frequency during output status, frequency change without transit time;
Measurement: voltage, current, current peak, frequency, active power, apparent power, power factor, voltage peak factor;
Online monitoring: monitor IGBT temperature, transformer temperature, fan speed, input voltage, and other parameters during output status;
Operating data recorders: keep the record of power supply status and alarm code automatically during alarming, saving maintenance time;
Fan speed will be automatically adjusted according to the temperature of the power supply to reduce the noise;
Lock key, user-friendly design, automatically locking without operation for 5 minutes to prevent operation mistakes;
8-inch large-screen color LCD, digital key operation;
Standard RS232, optional RS485, GPIB, Ethernet, analog control, and other remote communication/control.
